Fire sleeve, Priority

• Materials: Fiberglass, Silicone Rubber

• Working Temperature: Continuous working at 500°F (260°C), peaks at 3000°F (1650°C)

• Size Range: 3/8” (10mm) – 2” (50mm)

Firesleeve, Priority is constructed using knitted bulk fiberglass yarns in a flexible substrate, which is then coated with upgraded silicone rubber. This design is intended to protect various hoses, wires, and cables from the dangers posed by high temperature.

DESCRIPTION

HANTAI Fire sleeve Priority Grade is an essential material for protecting automobile parts. Made from knitted bulk fiberglass yarns in a flexible substrate and coated with upgraded silicone rubber, it offers better thermal insulation performance than standard firesleeves. This material can effectively safeguard parts from damage caused by high temperatures and other external environmental factors, thereby extending their service life and enhancing the safety and reliability of automobiles. In the automotive industry, firesleeves, such as HANTAI Firesleeve Priority Grade, are widely used in engine compartments, exhaust systems, electrical circuits, and other critical components, playing a crucial protective role.

CERTIFICATION

HANTAI Fire sleeve Standard Grade has obtained the following product certifications:

IEC 60684-2
Breakdown Voltage &
Bending at High / Low Temp

CHARACTERISTICS

PRODUCTS	Firesleeve, Priority / Fire Resistant Sleeve / Hose Protection Firesleeve
HANTAI PART NO#	HT11S-P (refers to the inner diameter=ID)
MATERIALS	Fiberglass, Silicone Rubber
CONSTRUCTION	Texturized and Knitted
SIZE RANGE	3/8” (10mm) – 2” (50mm)
WORKING TEMPERATURE	Continuous working at 500°F (260°C), peaks at 3000°F (1650°C)
COLOR	Standard: Iron Oxide Red; Others: Blue, Black, Yellow, Grey, etc. on request
ROLL LENGTH	20 meters / roll
AVAILABLE OPTIONS	Special bulk packaging (maximize productivity/minimize waste) Pre-cut short length Custom printing
